Thanks for the reply, but it's because I have some old files I would just like to see how I made it, but I have an old PC with v5 on so I just open them with it.

aaah it was an older file i was trying to open, v6 seems ok, but can i then open a v4 or v5 file.

how can i open a file from version 6 in version 8.
best regards Frank

Hi
No, there are no problems in simulation, it is only when it comes to the hardware.

Frank

I am from Denmark, and my English is not 100%.
So maybe I do not understand it exactly right.
But just so we agree on, 1 second is the same as 1000 millisecond.

Yes, strange, and the problem is only related to interrupt, delay in seconds works fine in all other routines.
try to find the problem.
I solve my problem by specifying any delay in milliseconds in my interrupt routines.
thank you

No it is not an option, since the processor must control my grass robot, and the interrupt function is used to stop it when it run into something,
therefore, must interrupt performed immediately, and I can not wait for it reaches back to the main program.
The problem is not long delay times ...

I have a problem.
I use the flow code v5 ​​but have no access to the v5 forum, but the problem is also in v4, so I write in v4 forum.
when I use a delay in an interrupt routine, it works fine if I set delay in milliseconds but not if I specify in seconds.
the same problem occurs when I call a macro ...

Thanks for answers
I just upgrade to v5, I would do it anyway, so it's ok.

Maybe I should just write a bit more about hardware.
I use a ECIO40 Processor and a EB37 card my SD card is a Transcend SD 1GB ultra industrial.
and I use Flow Code versions, v4.5.18.74 pro

why can I not write more than approx. 255 sectore (16KB) to an SD card ?
I've made a great program for logging 24 temperetursensore, I attach a small test file that also can not write more than the 255 sector ,although I try to write 600 sector?

Thank you,
it was just what I wanted, unfortunately I can not move one of the windows onto the screen no.2
but then I just move panel, etc. to the second screen so it's ok

Can I minimize windows so I can see more at once.
such that I can see main and macro programs simultaneously.
and possibly move some of them onto screen No. 2

Thank you,
but I think I have to stop interrupt while I pause, because it will not be triggered by a single pulse but of a whole series of pulses.
and only the rising edge at the first pulse I will trigger on until the break is gone.

I found the solution myself.
when ecio get power from USB port, it will interrupt all the time even when the gate b1 is connected to ground.
but when it is powered from an external source, there are no problems.
I also had to move reactivating the interrupt from interupt routine to the main ...

yes I've tried to connect all port B directly to ground.
but it makes no difference.

Hello.
I will have A0 = 0 when I switch B1 from low to high, with an interrupt function.
My little program works fine in the simulation, but in hardware it seems that it interrupts all the time without me touching port B.
I've tried to put B0 to B7 low without it helped.
I use a ECIO40P
What do ...

Yes it with PLL solved the problem thanks
I can tell that I have spent all day trying to figure out a problem
I had trouble controlling a servo motor, so I'd go back to the old pic16f877 which I knew worked with my program
but after I've made all the changes in configuration to program the 16f1827 I ...

yes it was great
but now I've got another problem
the processor running too fast or something
When I set up at led flasher and set a delay 1 sek so on time should be 1 sek the on time in realtime is about 275 mSek
but I have not tried to solve the problem myself yet
so I return if I do not solve it ...

Yes Yes I got it working I installed hiteck compileren and replaced teh file form last link.
thanks guys

Hej Jørgen det gav ingen ændring

hello and thanks for the reply
I installed the hitech compiler
And yes I use EB006
I set it to XTAL and fast on the board

And when I compil now
File name: C:\Documents and Settings\frank\My Documents\My Dropbox\flowcode\Programmer\servostyrring\1servo\testmid.c ...

Hi I try to program a PIC16F1827 but it does not work
I use Flowcode 4.3.7.63 / PPPv3 ver 3.9.12.26 / and EB-006-00-6 board
I start Flowcode and select PIC16F1827 and write a simpel led flash program to port B0.
In IC - Konfiguration - switch to Expert config screen
When I compile the ...

How can I know which pic I can use with various components of the flow code, I will use the component servo and I know that it works with a pic16f877 but not with a 16f88.
how can I tell which features a pic to be had (timer PWM, etc.) to work with a component
