To use 8MHz crystal and maximum allowed clock rates here are suggested settings clocks.jpg settings.jpg The Flowcode Timer interrupt dialog calculations are incorrect for STM devices (Flowcode does not know about multiple clocks) Therefore you need to work out yourself the prescaler and roll over va...

Have you downloaded and installed the FC11 PIC toolchain from Matrix website?
Ah, edit, I've just looked at your new msg.txt and see that you now have correct compiler.
Must be something else wrong.
Have you done a full component update?

You seem to be running an old version of XC8 (V1.45) Looks like your PIC compiler path is "C:\Program Files (x86)\Flowcode\Compilers\pic\" This would normally be "C:\Program Files (x86)\Flowcode\Common\Compilers\picv2\" Please check toolchain location in Global Settings->Location...

This is the C icon code from the demo, it also compiles OK on 32F030, I don't have 030 hardware to test it, although it worked fine on 411 so should also work on 030 Hope it helps // Example to enter Stop Mode HAL_SuspendTick(); // Stop SysTick to prevent immediate wakeup HAL_PWR_EnterSTOPMode(PWR_L...

Here's a target demo ... Note, this won't simulate

As for waking up every 5 minutes, this should be possible with a timer interrupt. Specifically with TIM2 and TIM5 that have 32 bit auto-reload counters. However I'm struggling to discover how to change these from the 16 bit value limit, using parameters in the device FCD. Matrix, is it possible to i...

No, I don't think it does. But after a super search, OK it was a bit of AI :roll: I found this ... // Example to enter Sleep Mode HAL_SuspendTick(); // Stop SysTick to prevent immediate wakeup HAL_PWR_EnterSLEEPMode(PWR_MAINREGULATOR_ON, PWR_SLEEPENTRY_WFI); HAL_ResumeTick(); // Resume SysTick after...

You have an error in macro Current_Meas
In the IF icon change to The other errors in the Bitmap drawing component and the ADC CAL will need attention from Matrix

Looks like AF9 got missed, try this ...

Have a look at these posts ... https://www.flowcode.co.uk/forums/viewtopic.php?t=3467 https://www.flowcode.co.uk/forums/viewtopic.php?p=21794#p21794 Ben, can you update the CAL file please, and I suspect the file versions might be in error, my V11 compiles this test project OK, but my CAL file is V1...
