Component: GLCD (E-BLOCKS 3) Dummy (Graphical Color)

Author	Matrix TSL
Version	1.0
Category	Graphical Color

Detailed description

No detailed description exists yet for this component

Examples

No additional examples

Macro reference

DrawBezier

	DrawBezier
Draws a quadratic Bezier curve with the current foreground colour from pixel location X0, Y0 to pixel location X2, Y2 using control point CX, CY.
- UINT	X0
Start X coordinate
- UINT	Y0
Start Y coordinate
- UINT	CX
Control point X coordinate
- UINT	CY
Control point Y coordinate
- UINT	X2
End X coordinate
- UINT	Y2
End Y coordinate
- UINT	Resolution
Number of segments to approximate the curve, 0 chooses an automatic value based on curve size.
- VOID	Return

DrawBitmap

	DrawBitmap
- STRING	Filename
- UINT	X1
- UINT	X2
- BYTE	Orientation
- BYTE	Transparency
- BYTE	Flip
- BYTE	Return

DrawBitmapScaled

	DrawBitmapScaled
- STRING	Filename
- UINT	X1
- UINT	X2
- UINT	Width
- UINT	Height
- BYTE	Orientation
- BYTE	Transparency
- BYTE	Flip
- BYTE	Return

DrawQRCode

	DrawQRCode
- UINT	X1
- UINT	Y1
- BYTE	Scaler
- STRING	Text
- VOID	Return

SendBinaryScene

	SendBinaryScene
- BYTE	Data
- UINT	Length
- VOID	Return

SetBitmapTransparency

	SetBitmapTransparency
Assigns the colour to use as the transparent mask. Anything in this specific colour will not be drawn when the DrawBitmap->Transparent parameter is set.
- BYTE	R
Colour channel. Range: 0 to 255
- BYTE	G
Colour channel. Range: 0 to 255
- BYTE	B
Colour channel. Range: 0 to 255
- VOID	Return

Property reference

Properties

Component Source Code

Please click here to download the component source project: FC_Comp_Source_GLCD_EB3_MatrixCapTouch_Dummy.fcfx

Please click here to view the component source code (Beta): FC_Comp_Source_GLCD_EB3_MatrixCapTouch_Dummy.fcfx
